Description
Product Information
SKU406686
Mfr Part#24G2SP
UPC685417727988
Display
Screen Size:23.8″
Panel Type:IPS
In Plane Switching (IPS) Support:IPS
Color:Black/Red
Features:Flicker-Free
Gaming Mode
HDR
Kensington Lock Slot
3-Sided Frameless
Cable Management
Low Motion Blur
Widescreen:Yes
Adaptive Sync:AMD FreeSync Technology
Maximum Resolution:1920 x 1080
Pixel Pitch:0.275mm
Native Refresh Rate:165Hz
Refresh Rate Details:60 Hz using VGA
144 Hz using HDMI
160 Hz Using DP
Response Time:1ms
Brightness:300 cd/m2
Native Contrast Ratio:1,100:1
Viewable Size:23.8″ Viewable Diagonal Size
Dynamic Contrast Ratio:20,000,000:1
Screen Coating:Anti-Glare
3H
Aspect Ratio:16:9
Viewing Angles:178 horizontal / 178 vertical viewing angles
Supported Resolutions:1920 x 1080, 1440 x 900, 1280 x 1024, 1280 x 800, 1152 x 864, 1024 x 768
Color Output:16.7 Million
Horizontal Scan Range:30 KHz – 200 KHz horizontal scan range
Vertical Scan Range:48 Hz – 165 Hz vertical scan range
Color Gamut:sRGB/ NTSC/ DCI-P3
Color Gamut Details:DCI-P3 87 %
sRGB 126 %
NTSC 96 %
Bit Depth:8-Bit (6-Bit+FRC)
Features
Stand Adjustment:Height
Pivot
Tilt
Swivel
Tilt Range:-5 degrees to +23 degrees
Turning Rate:Pivot: + 90; Swivel: +/- 30; Height: 130mm
Controls
Controls:Source/Auto/Exit, left/Game mode, Right/ShadowControl Menu/Enter, Power
Connectivity
Ports:1 x VGA 15-pin
1 x 3.5 mm Audio Output
2 x HDMI 2.0
1 x DisplayPort 1.2
Power
Voltage Required:100 to 240 VAC / 50 or 60 Hz 3Hz / 1.5 A (Max)
Power Consumption Operational (Standby):<21 watts=""><0.3>
Physical Specifications
Box Dimensions (WxDxH):23.82 x 7.24 x 19.37 in. (605.03 x 183.90 x 492.00 mm)
VESA Mount Compatibility:100mm x 100mm (3.9 x 3.9 in.)
Width:21.22 in. (539.00 mm)
Depth:8.95 in. (227.33 mm)
Height:14.75 in. (374.65 mm)
Weight:9.37 lbs. (4.25 kg)
Environmental Specifications
Temperature – Operating (°C):32 to 104? F (0 to 40 C)
Temperature – Non-Operating (°C):-13 to 131F (-20 to 55C)
ROHS Compliant:Yes
Certifications:CE
CCC
FCC
Humidity Range:10% to 85% non-condensing
Package Contents
What's in the Box:1 x 24″ Monitor, 1 x Power Cord, 1 x HDMI cable, 1 x DP Cable, 1 x QSG
Warranty
Parts:3 Years Limited
Labor:3 Years Limited
