Description
Product Information
SKU194696
Mfr Part#NT-DESKMINI H47
UPC4710483932014
Motherboard
Socket Type:LGA 1200
Supported Processors:Supports Intel 10th Gen LGA1200 Processors (Max. TDP 65W)
North Bridge:Intel H470
Memory Capacity:64GB
Memory Slots:2 x 260 pin SO-DIMM
Memory Slots (Available):2
Memory Type:DDR4-2933
Processor
CPU Brand:Intel
Compatibility:Intel H470
Memory
Memory Speed:PC4-23400
Memory Speed (MHz):DDR4-2933
Storage
Hard Drive Included:No
SSD / NVMe Included:No
Computer Case
Motherboard Support:UCFF
Drive Controllers
SATA Express:2 x SATA 6.0Gb/s
1 x M.2 NVMe
RAID Support:RAID 0
RAID 1
Communications
LAN Chipset:Intel i219-V
LAN:10/100/1000 Mbps
Audio
Sound Card:Realtek ALC233
Ports & Connectors
Rear Ports:4 x USB 3.2 (Gen 1 Type-A)
1 x USB 3.2 (Gen 1 Type-C)
Front Ports:1 x 3.5mm Combo Headphone/Microphone Jack
1 x USB 3.2 (Gen 2 Type-A)
1 x USB 3.2 (Gen 1 Type-C)
Physical Specifications
Width:3.15 in. (80.00 mm)
Depth:6.10 in. (155.00 mm)
Height:6.10 in. (155.00 mm)
Max CPU Heatsink Height:1.81 in. (46.00 mm)
Box Dimensions (WxDxH):12.00 x 5.00 x 9.00 in. (304.80 x 127.00 x 228.60 mm)
What’s in the Box
Operating System Included:No
