Description
Product Information
SKU521773
Mfr Part#PN50BB7000XFD12
UPC195553461405
Motherboard
Motherboard:ASUS PN50 Motherboard
Memory Capacity:64GB
Memory Slots:2 x 260 pin SO-DIMM
Memory Slots (Available):2
Memory Type:DDR4-3200
Processor
Processor:AMD Ryzen 7 4700U 2.0GHz
Heatsink:ASUS PN50 Heatsink
CPU Brand:AMD
CPU Core:Renoir
Cores:Eight-Core
CPU Speed:4700U (2.00GHz)
Turbo Boost Speed:4.10GHz
Level 3 Cache:8MB
TDP (Thermal Design Power):15 Watts
Level 2 Cache:4MB
Memory
Memory:Memory Not Included
Memory Included:No
Storage
Hard Drive:Hard Drive Not Included
Hard Drive Included:No
SSD / NVMe:SSD Not Included
SSD / NVMe Included:No
Computer Case
Liquid Cooling Included:No
Case:ASUS PN50 Mini PC Case
Form Factor:UCFF
Drive Controllers
SATA Express:1 x SATA
1 x M.2 NVMe M-Key
Communications
LAN Chipset:Realtek 8111EP
LAN:10/100/1000 Mbps
Wireless Technology:802.11a
802.11b
802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
Bluetooth:Bluetooth 5.0
Video
Graphics Card:AMD Radeon Graphics
GPU Chipset:AMD Radeon Vega 7
GPU Brand:AMD
Multimedia Drives
Multimedia Drive Included:No
Expansion Bays
Internal 2.5" Drive Bays:1 Total, 1 Available
Ports & Connectors
Front Ports:1 x USB 3.2 (Gen 2 Type-C)
1 x 4-in-1 Card Reader
1 x USB 3.2 (Gen 1 Type-A)
Rear Ports:1 x RJ-45
1 x HDMI 2.0
2 x USB 3.2 (Gen 1 Type-A)
1 x USB 3.2 (Gen 2 Type-C)
1 x DisplayPort 1.2
Power
Power Supply:ASUS 90 Watt Power Adapter
Physical Specifications
Width:4.50 in. (114.30 mm)
Depth:4.50 in. (114.30 mm)
Height:1.93 in. (49.00 mm)
Weight:1.50 lbs. (0.68 kg)
Box Dimensions (WxDxH):11.80 x 7.50 x 2.70 in. (299.72 x 190.50 x 68.58 mm)
What’s in the Box
Operating System Included:No
