Ball Bearing Chuck, 14N Super Chuck®
The JACOBS Super Chuck® ball bearing chuck is specifically engineered for heavy-duty, close tolerance production drilling. It is adaptable to a wide range of production drilling equipment, jig borers, milling machines, lathes, and radials. Utilizing a ball thrust bearing to reduce friction in the chuck closing mechanism, it permits the application of more gripping force on drill shanks to maximize drilling torque under the most demanding machining conditions.
Features
T.I.R. 0.003 In. maximum at half capacity
Each chuck 100% inspected for performance and precision
Fluted sleeve standard
Through-hardened sleeve teeth plus hardened nose and keyholes provide outstanding wear resistance
One-piece sleeve eliminates crack between driving teeth often found in other designs
Jaws center-ground for straightness and alignment
Ball bearing construction maximizes gripping force and drilling accuracy
Specifications
Chuck Capacity (in)
0.5
Chuck Design
Keyed
Chuck Key Included
Yes
Chuck Key Storage
No
Chuck Size
1/2 In
Color / Finish
Natural
Country of Origin
Taiwan
Acme Tools Brand Name
JACOBS
Assembled Weight (lbs)
2.2
Acme Tools Part Number
JCM30221
